Feiya International Group Ltd Anping Branch Factory---Xinlu Wire Mesh Products Co.,ltd WEDGE WIRE PANEL
Feiya International Group Ltd Anping Branch Factory---Xinlu Wire Mesh Products Co.,ltd offer largest range of Welded Wedge Wire Screen Panels for various applications such as sizing, separation & dewatering.
Better Flatness assures Better Production & Dewatering
There are many combinations available for wedge wire / trapezoidal wire and internal profile support rods. We can offer the best possible combinations to achieve higher open area and higher life simultaneously.
We can produce Wedge Wire Panels in widths up to 3000 mm and lengths up to 6000 mm in single piece construction. The slots can be offered right from 50 microns rating to 750 microns & above.
Specification:
1.Material: stainless steel(304, 304L, 316, 316L etc.)
low carbon, low carbon galvanized steel(LCG),
2.Diameter: Normal size is 89mm 114mm, 168mm 219mm 245mm 273mm 325mm 406mm 426mm and etc.
More size can be made according to customer's requirment
3.Slot: 0.1mm, 0.2mm, 0.5mm, 0.75mm, 1mm, 1.5mm and etc.
Also can be made as customer's requirement.
4. Length: 1-6m (2.9 or 5.8m is suitable for container loading)
Advantage:
High flow rates
Non-clogging slot
Reduction cost in operating
Data reference table:
| PROFILE WIRE | | | | | | | | |
| WIDTH(mm) | 1.50 | 1.50 | 2.30 | 2.30 | 1.80 | 3.00 | 3.70 | 3.30 |
| HEIGHT(mm) | 2.20 | 2.50 | 2.70 | 3.60 | 4.30 | 4.70 | 5.60 | 6.30 |
| SUPPORT ROD | | | | | |
ROUND |
| WIDTH(mm) | 2.30 | 2.30 | 3.00 | 3.70 | 3.30 | Ø2.5--Ø5mm |
| HEIGHT(mm) | 2.70 | 3.60 | 4.70 | 5.60 | 6.30 | ---- |
Any inquiry please don't hesitate to contact us !(whatsApp+86-13315867171)
Hope we can work together soon.
Contact:feiyatrade@hotmail.com
Skype: terastar.lee
---------------------------------------------------------------------------------------------------------------
Our factory Xinlu Wire Mesh product co., Ltd located in Anping country, Hebei Province, China.
Our mainly products are: stainless steel vee sharped wire / wrap wire, johnson screeen, water well screen / rod based wire wrapped screen, wedge wire screen, reverse wedge wire screen, stainess steel strainer pipe, v wire slot tube, perfect roundness well screen pipe, dewatering well screen, dewatering screen panel, wedge wire grating, v wire flat panel, screen nozzle, water and gas strainer nozzle, stainless steel filter nozzle, wedge wire support grids, sieve bend plate, v wire screens, ARC screen, filter bottom nozzle, stainless steel lateral screens, wedge wire filter candles, Rotary drum screens, strainer cylinder, sand control well screen, oil well screen, rod basedc ontinuous slot screens, header and hub laterals & hub radial laterals etc
